Com air 2.2

400V 12 m3/uur

Com air 2.2
o.a. *Prijzen zijn exclusief btw
ComAir 2.2
werkdruk
1,2 MPa
capaciteit
12  [m³/h]
capaciteit
200 [l/min]
gewicht
105 [kg]
afmeting (axbxc)
1270x560x920        [mm]
inhoud persluchttank
120  [l]
aansluiting op persluchttank
G1/2  [mm]
hoogte aansluiting op persluchttank
275 (d)
omgevingstemperatuur
5 -  40  [°C]
luchttemperatuur op outlet [°C]
40  [°C]
geluidsniveau
77 [dB(A)]
aantal cilinders I / II stage [pcs]
3
diameter of cilinders I / II stage
-- [mm]
zuigerslag
-- [mm]
toerental compressor
810 [rpm]
motorvermogen
2,2 [kW]
toerental motor
3000 [rpm]
voedingsspanning [V]
400 ( -10%  +5%)
voedingskabel
5x2,5 [mm²]
zekering / spanningsbeveiliging
16 [A]
