Com air 4.2

400V, 30m3 / uur

Com air 4.2
o.a. *Prices are exclusive of VAT
ComAir 4.2
werkdruk
1.2 MPa
capaciteit
30  [m³/h]
capaciteit
500 [l/min]
gewicht
160 [kg]
afmeting (axbxc)
1500x508x1277        [mm]
inhoud persluchttank
240  [l]
aansluiting op persluchttank
G3/4  [mm]
hoogte aansluiting op persluchttank
384 (d)
omgevingstemperatuur
5 - 40  [°C]
luchttemperatuur op outlet [°C]
40 [°C]
geluidsniveau
83 [dB(A)]
aantal cilinders I / II stage [pcs]
2
diameter of cilinders I / II stage
-- [mm]
zuigerslag
-- [mm]
toerental compressor
830 [rpm]
motorvermogen
4,0 [kW]
toerental motor
3000 [rpm]
voedingsspanning [V]
400 ( -10%  +5%)
voedingskabel
5x2,5 [mm²]
zekering / spanningsbeveiliging
25 [A]
